- FRAMESET
-
- Seat Binder
- Alloy, 38.6mm
-
- Frame
- Specialized M5 premium alloy, headset adjust, BB height adjust, S-Sizing, internal cable routing, 150mm travel, 148mm spacing
- E-BIKE
-
- Wiring Harness
- Custom Specialized wiring harness
-
- Charger
- Custom charger, 42V4A w/ Rosenberger plug, 100-240V
-
- Motor
- Specialized 2.2 Custom RX Trail Tuned Motor
-
- Battery
- Specialized M3-700, Integrated battery, 700Wh
-
- UI/Remote
- Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote
- ACCESSORIES
-
- SWAT
- SWAT CC steerer tube integrated tool with chain tool and link
- SUSPENSION
-
- Fork
- Ohlins RXF38, 29", 160mm travel
-
- Rear Shock
- Ohlins TTX coil, 210x55mm S2: 411lbs, S3: 457lbs, S4: 502lbs, S5: 548lbs, S6: 605lbs
- COCKPIT
-
- Stem
- Alloy Trail Stem, 35mm bar bore
-
- Grips
- Diety Lockjaw grips
-
- Saddle
- Bridge, 155/143mm, Hollow Ti-rails
-
- Handlebars
- Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
-
- SeatPost
- X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4/S5: 170mm, S6: 190mm
- BRAKES
-
- Front Brake
- TRP DH-R Evo brakes, 220mm rotor
-
- Rear Brake
- TRP DH-R Evo brakes, 220mm rotor
- DRIVETRAIN
-
- Crankset
- Praxis forged M30, custom offset, 160mm
-
- Chain
- SRAM GX Eagle Transmission Flattop Chain
-
- Chainrings
- SRAM Eagle Transmission 34t Steel, 104BCD
-
- Cassette
- SRAM GX Eagle Transmission Cassette, 12spd, 10-52t
-
- Shift Levers
- SRAM AXS POD Controller
-
- Rear Derailleur
- SRAM GX Eagle Transmission Derailleur
- WHEELS & TIRES
-
- Rear Hub
- DT Swiss 370, 32h, 12x148
-
- Front Hub
- DT Swiss 370, 28h, 15x110
-
- Rear Tire
- Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 27.5x2.3"
-
- Front Tire
- Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
-
- Spokes
- Sapim Force
-
- Rims
- Roval Traverse 29 Alloy, 30mm internal width, 28h: Roval Traverse 27.5 Alloy, 30mm internal width, 32h
-
- Inner Tubes
- Standard, Presta Valve
|
