Leírás és Paraméterek
Turbo Vado 3.0 Step-Through Technical Specifications
FRAMESET
Frame
E5 Aluminum, bottom bracket motor mount, fully integrated & lockable downtube battery, internal cable routing, lock and front rack mount
Fork
SR Suntour MobieA32, 80mm travel, lockout, fender-mounts, integrated light mount
Seat Binder
Alloy, bolt-type, 34.9mm
COCKPIT
Stem
Specialized Flowset, 3D-forged alloy, 20-degree rise, 31.8mm clamp
Handlebars
Specialized, alloy, 15-degree backsweep, 46mm rise, 31.8mm
Saddle
Rivo Sport, steel rails, 155mm
SeatPost
Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
Grips
Body Geometry Women's Contour
BRAKES
Front Brake
Shimano BR-MT200, hydraulic disc, 180mm Centerlock
Rear Brake
Shimano BR-MT200, hydraulic disc, 180mm Centerlock
DRIVETRAIN
Rear Derailleur
Shimano Alivio, SGS, 9-speed
Shift Levers
Shimano Alivio, 9-speed w/ Optical Gear Display
Cassette
Shimano CS-HG400, 9-speed, 11-36t
Chain
KMC e9T, 9-speed w/ Missing Link™
Crankset
Custom alloy forged crankarms
Chainrings
Praxis, 48T, 104BCD
Chaincase
custom chaincover
ACCESSORIES
Pedals
Specialized Commuter w/ grip tape & reflectors
Headlight
Lezyne EBIKE MINI STVZO E65, 210 Lumen, 12V
Taillight
Spanninga Commuter Glow XE, 12V
Kickstand
Specialized kickstand, 40mm mount
Rack
Specialized rack, MIK HD inteface, built-in pannier mounts, 27kg max load
Fenders
Specialized DRYTECH fenders, 65mm width, aluminum fenderstay
Bell
Simple bell
WHEELS
Rims
650b disc, double-wall alloy, pinned, 32h
Front Hub
Shimano MT400, Centerlock, 15x100mm, 32h
Rear Hub
Shimano MT400-B, Centerlock, 12x148 Boost, 32h
Spokes
DT Swiss Industry
Front Tire
Pathfinder Sport Reflect, 650Bx2.3
Rear Tire
Pathfinder Sport Reflect, 650Bx2.3
Inner Tubes
Schrader, 40mm valve
E-BIKE
Motor
Specialized 2.0E, 50Nm torque, custom tuned motor, 250W nominal
UI/Remote
MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages
Battery
Specialized U2-530, alloy casing, state of charge display, 530Wh
Charger
Custom charger, 42V4A w/ Rosenberger plug, 230V
Wiring Harness
Custom wire harness
| Felhasználási terület | Trekking-túra (főleg aszfalton) |
| maximum_testmagassag | 178cm |
| minimum_testmagassag | 168cm |
| Motor maximális nyomatéka | 50 |
Paraméterek
| Felhasználási terület | Trekking-túra (főleg aszfalton) |
| maximum_testmagassag | 178cm |
| minimum_testmagassag | 168cm |
| Motor maximális nyomatéka | 50 |
Leírás
Turbo Vado 3.0 Step-Through Technical Specifications
FRAMESET
Frame
E5 Aluminum, bottom bracket motor mount, fully integrated & lockable downtube battery, internal cable routing, lock and front rack mount
Fork
SR Suntour MobieA32, 80mm travel, lockout, fender-mounts, integrated light mount
Seat Binder
Alloy, bolt-type, 34.9mm
COCKPIT
Stem
Specialized Flowset, 3D-forged alloy, 20-degree rise, 31.8mm clamp
Handlebars
Specialized, alloy, 15-degree backsweep, 46mm rise, 31.8mm
Saddle
Rivo Sport, steel rails, 155mm
SeatPost
Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
Grips
Body Geometry Women's Contour
BRAKES
Front Brake
Shimano BR-MT200, hydraulic disc, 180mm Centerlock
Rear Brake
Shimano BR-MT200, hydraulic disc, 180mm Centerlock
DRIVETRAIN
Rear Derailleur
Shimano Alivio, SGS, 9-speed
Shift Levers
Shimano Alivio, 9-speed w/ Optical Gear Display
Cassette
Shimano CS-HG400, 9-speed, 11-36t
Chain
KMC e9T, 9-speed w/ Missing Link™
Crankset
Custom alloy forged crankarms
Chainrings
Praxis, 48T, 104BCD
Chaincase
custom chaincover
ACCESSORIES
Pedals
Specialized Commuter w/ grip tape & reflectors
Headlight
Lezyne EBIKE MINI STVZO E65, 210 Lumen, 12V
Taillight
Spanninga Commuter Glow XE, 12V
Kickstand
Specialized kickstand, 40mm mount
Rack
Specialized rack, MIK HD inteface, built-in pannier mounts, 27kg max load
Fenders
Specialized DRYTECH fenders, 65mm width, aluminum fenderstay
Bell
Simple bell
WHEELS
Rims
650b disc, double-wall alloy, pinned, 32h
Front Hub
Shimano MT400, Centerlock, 15x100mm, 32h
Rear Hub
Shimano MT400-B, Centerlock, 12x148 Boost, 32h
Spokes
DT Swiss Industry
Front Tire
Pathfinder Sport Reflect, 650Bx2.3
Rear Tire
Pathfinder Sport Reflect, 650Bx2.3
Inner Tubes
Schrader, 40mm valve
E-BIKE
Motor
Specialized 2.0E, 50Nm torque, custom tuned motor, 250W nominal
UI/Remote
MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages
Battery
Specialized U2-530, alloy casing, state of charge display, 530Wh
Charger
Custom charger, 42V4A w/ Rosenberger plug, 230V
Wiring Harness
Custom wire harness
