- FRAMESET
-
- SWAT
- SWAT 4.0 internal downtube storage
-
- Frame
- FACT 11m carbon chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
-
- Seat Binder
- Alloy, 38.6mm
- SUSPENSION
-
- Fork
- FOX FLOAT 36 Performance Elite, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm QR axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
-
- Rear Shock
- FOX FLOAT Performance Elite with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment, S1:210x52.5mm, S2-S6:210x55mm
- COCKPIT
-
- Stem
- Alloy Trail Stem, 35mm bar bore
-
- Saddle
- Bridge Comp, Hollow Cr-mo rails, S1-S2: 155mm, S3-S6: 143mm
-
- Grips
- Deity Lockjaw
-
- Handlebars
- Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S4: 800 width, 30mm rise: S5-S6: 800 width, 40mm rise
-
- SeatPost
- PNW Loam Dropper, tool-less travel adjust, Range lever, 34.9, S1: 125mm, S2: 150mm, S3: 170mm, S4-S6: 200mm
- BRAKES
-
- Front Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor
-
- Rear Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 200mm HS2 Rotor
- DRIVETRAIN
-
- Chain
- SRAM GX Eagle Transmission Flattop Chain
-
- Cassette
- SRAM GX Eagle Transmission Cassette, 12spd, 10-52t
-
- Bottom Bracket
- SRAM DUB, BSA 73mm Wide, Threaded
-
- Shift Levers
- SRAM AXS POD Controller
-
- Crankset
- SRAM GX Eagle Crankset, 32T ring, Integrated Guard, 55mm Chainline, S1-S3:165mm, S4-S6: 170mm
-
- Rear Derailleur
- SRAM GX Eagle Transmission Derailleur
- WHEELS & TIRES
-
- Rims
- Roval Traverse, hookless alloy, 30mm inner width, tubeless ready, Front: 29, Rear: S1-S2: 27.5, S3- S6: 29
-
- Front Hub
- DT Swiss 370, 15x110mm, 28h
-
- Rear Hub
- DT Swiss 370, 12x148mm, 28h
-
- Rear Tire
- Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, S1-S2: 27.5x2.3, S3- S6: 29x2.3"
-
- Spokes
- Sapim Force
-
- Inner Tubes
- Standard, Presta valve
-
- Front Tire
- Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
- PRODUCT DETAILS
-
- Product ID
- 221401
- WEIGHT
-
- Weight
- 14.47kg (31 lb, 14.4 oz)
-
- Weight Size
- S4
|
